1756-M22 1756M22 অ্যালেন ব্র্যাডলি কন্ট্রোললগিক্স লগিক্স 5555 ননভোলটাইল মেমরি মডিউল
Good ভাল দামের জন্য এখানে ক্লিক করুন 1756-M22
ব্র্যান্ড / প্রস্তুতকর্তা | অ্যালেন-ব্র্যাডলি / ইউ এস এ |
অংশ সংখ্যা |
1756-M22 |
বিকল্প অংশ নম্বর | 1756-M22 |
বিবরণ | মোট সার্ভার |
Dimennsions |
18x12.6x12cm |
ওজন | 0.7 কেজি |
পণ্যের বিবরণ
The AB 1756-M22 module is a 750 KB non-volatile memory module for AB ControlLogix 5555 controllers. অ্যালেন-ব্র্যাডলি 1756-M22 মডিউলটি অ্যালেন-ব্র্যাডলি কন্ট্রোললগিক্স 5555 নিয়ামকগুলির জন্য একটি 750 কেবি অ-উদ্বায়ী মেমরি মডিউল। ControlLogix controllers with which the 1756-M22 module is compatible include the 1756-L55, 1756-L55M12, 1756-L55M13, 1756-L55M14, 1756-L55M16, 1756-L55M22, 1756-L55M23, and the 1756-L55M24 controllers. কন্ট্রোললিক্স্স কন্ট্রোলারগুলির সাথে 1756-M22 মডিউলটি সামঞ্জস্যপূর্ণ 1756-L55, 1756-L55M12, 1756-L55M13, 1756-L55M14, 1756-L55M16, 1756-L55M22, 1756-L55M23, এবং 1756-L55M24 নিয়ন্ত্রকগুলি। Firmware version 10.x or later is required to be used on the controllers for them to work with the 1756-M22 memory module. 1756-M22 মেমরি মডিউলটির সাথে কাজ করার জন্য ফার্মওয়্যার সংস্করণ 10.x বা তারপরে নিয়ামকদের তাদের ব্যবহার করা দরকার। If the controllers have an older firmware version, the controller firmware must be upgraded prior to memory module installation. যদি কন্ট্রোলারগুলির একটি পুরানো ফার্মওয়্যার সংস্করণ থাকে তবে মেমরি মডিউল ইনস্টল করার আগে কন্ট্রোলার ফার্মওয়্যারটি আপগ্রেড করতে হবে। To prevent damage to the memory module, the battery must be disconnected from the controller before installing or replacing the memory module. মেমরির মডিউলটির ক্ষতি রোধ করতে, মেমরি মডিউলটি ইনস্টল বা প্রতিস্থাপন করার আগে ব্যাটারিটি নিয়ামক থেকে সংযোগ বিচ্ছিন্ন করতে হবে। The installation or replacement of the 1756-M22 module on the ControlLogix 5555 controller requires the following 4 steps: removing the side plate of the controller, removing the existing memory board, installing the new memory board, and replacing the controller side plate. কন্ট্রোললগিক্স 5555 কন্ট্রোলারে 1756-M22 মডিউলটি স্থাপন বা প্রতিস্থাপনের জন্য নিম্নলিখিত 4 টি পদক্ষেপ প্রয়োজন: নিয়ামকের সাইড প্লেটটি সরিয়ে, বিদ্যমান মেমরি বোর্ডটি সরিয়ে, নতুন মেমরি বোর্ড ইনস্টল করা, এবং নিয়ামক সাইড প্লেট প্রতিস্থাপন। Labels can be placed on the side of the controller to identify the type of memory board that is installed. ইনস্টল করা মেমরি বোর্ডের ধরণ সনাক্তকরণের জন্য নিয়ামকের পাশে লেবেল স্থাপন করা যেতে পারে।
The 1756-M22 module is sensitive to ESD. 1756-M22 মডিউলটি ESD এর প্রতি সংবেদনশীল। The following precautions need to be followed to prevent damage to the module: touching a grounded object to discharge static, wearing a grounded wrist strap, avoiding touching the connector or module components, using static-safe workstations, and storing the module in static-safe containers. মডিউলটির ক্ষতি রোধ করার জন্য নিম্নলিখিত সতর্কতাগুলি অনুসরণ করা দরকার: স্থিতিশীল স্রাবের জন্য গ্রাউন্ডেড অবজেক্টটিকে স্পর্শ করা, গ্রাউন্ডেড কব্জির স্ট্র্যাপ পরা, সংযোজক বা মডিউল উপাদানগুলির স্পর্শ এড়ানো, স্ট্যাটিক-নিরাপদ ওয়ার্কস্টেশনগুলি ব্যবহার করা এবং স্ট্যাটিক-সেফটিতে মডিউলটি সংরক্ষণ করা পাত্রে। The operating temperature range for the 1756-M22 module is from 0 to 60 degrees Celsius. 1756-M22 মডিউলটির অপারেটিং তাপমাত্রা 0 থেকে 60 ডিগ্রি সেলসিয়াস অবধি। The storage temperature range for the module is from -40 to 85 degrees Celsius. মডিউলটির জন্য স্টোরেজ তাপমাত্রার পরিসীমা -40 থেকে 85 ডিগ্রি সেলসিয়াস। The range for the relative humidity is from 5 to 95% (non-condensing). আপেক্ষিক আর্দ্রতার পরিধি 5 থেকে 95% (নন-কনডেনসিং) পর্যন্ত। The operating and non-operating shock ratings for the module are 30 G and 50 G, respectively. মডিউলটির অপারেটিং এবং অপারেটিং শক রেটিং যথাক্রমে 30 জি এবং 50 জি। The enclosure of the module is open and it complies with the T4 North American temperature code and the T4 IEC temperature code. মডিউলটির ঘেরটি খোলা রয়েছে এবং এটি টি 4 উত্তর আমেরিকান তাপমাত্রা কোড এবং টি 4 আইইসি তাপমাত্রা কোডের সাথে সম্মতি দেয়।
আমাদের সেবা
100% পূর্ণ নতুন - আসল কারখানার সীল
ওয়্যারেন্টি: 12 মাস
প্যাকেজ: কার্টনগুলির সাথে মূল প্যাকিং
বিতরণ সময়: প্রদানের 3 দিনের মধ্যে প্রেরণ
